Setup Apple Mac for Machine Learning with PyTorch (works for all M1 and M2 chips)
Prepare your M1, M1 Pro, M1 Max, M1 Ultra or M2 Mac for data science and machine learning with accelerated PyTorch for Mac.
You: Have an Apple Silicon Mac (any of the M1 or M2 chip variants) and would like to set it up for data science and machine learning.
This blog post: Helps you install various software tools such as Homebrew and Miniforge3 to use to install various data science and machine learning tools such as PyTorch.
We'll also be getting PyTorch to run on the Apple Silicon GPU for (hopefully) faster computing.
Resources
- Get the code on GitHub.
- Got a problem? Create an issue on GitHub
- Want to set up TensorFlow? See my article for setting up TensorFlow on Mac
- See the video walkthrough version of this article on YouTube:
Setup a machine learning environment with PyTorch on Mac (short version)
Note: As of June 30 2022, accelerated PyTorch for Mac (PyTorch using the Apple Silicon GPU) is still in beta, so expect some rough edges.
Requirements:
- Apple Silicon Mac (M1, M2, M1 Pro, M1 Max, M1 Ultra, etc).
- PyTorch 1.12.0+ (v1.12.0 is the minimum PyTorch version for running accelerated training on Mac).
- macOS 12.3+ (PyTorch will work on previous versions but the GPU on your Mac won't get used, this means slower code).
Steps
- Download and install Homebrew from https://brew.sh. Follow the steps it prompts you to go through after installation.
- Download Miniforge3 (Conda installer) for macOS arm64 chips (M1, M1 Pro, M1 Max, M1 Ultra, M2).
- Open Terminal and run these commands to install Miniforge3 into home directory.
chmod +x ~/Downloads/Miniforge3-MacOSX-arm64.sh
sh ~/Downloads/Miniforge3-MacOSX-arm64.sh
source ~/miniforge3/bin/activate
4. Restart terminal.
5. Create a directory to setup a PyTorch environment.
mkdir pytorch-test
cd pytorch-test
6. Make and activate a Conda environment.
Note: Python 3.8 is the most stable for using the following setup.
conda create --prefix ./env python=3.8
conda activate ./env
7. Install PyTorch 1.12.0+ default version for Mac with pip from the PyTorch getting started page.
pip3 install torch torchvision torchaudio
This will install the following:
Installing collected packages: urllib3, typing-extensions, pillow, numpy, idna, charset-normalizer, certifi, torch, requests, torchvision, torchaudio
8. Install common data science packages.
conda install jupyter pandas numpy matplotlib scikit-learn tqdm
9. Start Jupyter.
jupyter notebook
10. Create a new notebook by "New" -> "Notebook: Python 3 (ipykernel)" and run the following code to verfiy all the dependencies are available and check PyTorch version/GPU access.
import torch
import numpy as np
import pandas as pd
import sklearn
import matplotlib.pyplot as plt
print(f"PyTorch version: {torch.__version__}")
# Check PyTorch has access to MPS (Metal Performance Shader, Apple's GPU architecture)
print(f"Is MPS (Metal Performance Shader) built? {torch.backends.mps.is_built()}")
print(f"Is MPS available? {torch.backends.mps.is_available()}")
# Set the device
device = "mps" if torch.backends.mps.is_available() else "cpu"
print(f"Using device: {device}")
If it all worked, you should see something like:
PyTorch version: 1.12.0
Is MPS (Metal Performance Shader) built? True
Is MPS available? True
Using device: mps
Note: See more on running MPS as a backend in the PyTorch documentation.
11. To run data/models on an Apple Silicon GPU, use the PyTorch device name "mps"
with .to("mps")
. MPS stands for Metal Performance Shaders, Metal is Apple's GPU framework.
import torch
# Set the device
device = "mps" if torch.backends.mps.is_available() else "cpu"
# Create data and send it to the device
x = torch.rand(size=(3, 4)).to(device)
x
Finally, you should get something like this:
tensor([[2.6020e-01, 9.6467e-01, 7.5282e-01, 1.8063e-01],
[7.0760e-02, 9.8610e-01, 6.5195e-01, 7.5700e-01],
[3.4065e-01, 1.8971e-01, 6.0876e-01, 9.3907e-01]], device='mps:0')
Congratulations! Your Apple Silicon device is now running PyTorch and a handful of other helpful data science and machine learning libraries.
Results
Last update: 23 May 2022
Benchmark results were gathered with the notebook 01_cifar10_tinyvgg.ipynb
.
Running TinyVGG on CIFAR10 dataset with batch size 32 and image size 32*32:
Running TinyVGG on CIFAR10 dataset with batch size 32 and image size 224*224:
Looks like the "mps"
device shines when the GPU is getting utilized more. However, since accelerated PyTorch for Mac is still in beta, I'm sure there's room for improvement.
How to set up a PyTorch environment on Apple Silicon using Miniforge (longer version)
If you're new to creating environments, using an Apple Silicon Mac (M1, M1 Pro, M1 Max, M1 Ultra, M2) and would like to get started running PyTorch and other data science libraries, follow the below steps.
Note: You're going to see the term "package manager" a lot below. Think of it like this: a package manager is a piece of software that helps you install other pieces (packages) of software.
Installing package managers (Homebrew and Miniforge)
- Download and install Homebrew from https://brew.sh. Homebrew is a package manager that sets up a lot of useful things on your machine, including Command Line Tools for Xcode, you'll need this to run things like
git
. The command to install Homebrew will look something like:
/bin/bash -c "$(curl -fsSL https://raw.githubusercontent.com/Homebrew/install/HEAD/install.sh)"
It will explain what it's doing and what you need to do as you go.
2. Download the most compatible version of Miniforge (minimal installer for Conda specific to conda-forge, Conda is another package manager and conda-forge is a Conda channel) from GitHub.
If you're using an M1 variant Mac, it's "Miniforge3-MacOSX-arm64" <- click for direct download.
Clicking the link above will download a shell file called Miniforge3-MacOSX-arm64.sh
to your Downloads
folder (unless otherwise specified).
3. Open Terminal.
4. We've now got a shell file capable of installing Miniforge, but to do so we'll have to modify it's permissions to make it executable.
To do so, we'll run the command chmod -x FILE_NAME
which stands for "change mode of FILE_NAME to -executable".
We'll then execute (run) the program using sh
.
chmod +x ~/Downloads/Miniforge3-MacOSX-arm64.sh
sh ~/Downloads/Miniforge3-MacOSX-arm64.sh
5. This should install Miniforge3 into your home directory (~/
stands for "Home" on Mac).
To check this, we can try to activate the (base)
environment, we can do so using the source
command.
source ~/miniforge3/bin/activate
If it worked, you should see something like the following in your terminal window.
(base) daniel@Daniels-MBP ~ %
6. We've just installed some new software and for it to fully work, we'll need to restart terminal.
Creating a PyTorch environment
Now we've got the package managers we need, it's time to install PyTorch.
Let's set up a folder called pytorch-test
(you can call this anything you want) and install everything in there to make sure it's working.
Note: An environment is like a virtual room on your computer. For example, you use the kitchen in your house for cooking because it's got all the tools you need. It would be strange to have an oven in your bedroom. The same thing on your computer. If you're going to be working on specific software, you'll want it all in one place and not scattered everywhere else.
- Make a directory called
pytorch-test
. This is the directory we're going to be storing our environment. And inside the environment will be the software tools we need to run PyTorch, especially PyTorch on the Apple Silicon GPU.
We can do so with the mkdir
command which stands for "make directory".
mkdir pytorch-test
2. Change into pytorch-test
. For the rest of the commands we'll be running them inside the directory pytorch-test
so we need to change into it.
We can do this with the cd
command which stands for "change directory".
cd pytorch-test
3. Now we're inside the pyorch-test
directory, let's create a new Conda environment using the conda
command (this command was installed when we installed Miniforge above).
We do so using conda create --prefix ./env
which stands for "conda create an environment with the name file/path/to/this/folder/env
". The .
stands for "everything before".
For example, if I didn't use the ./env
, my filepath looks like: /Users/daniel/pytorch-test/env
conda create --prefix ./env
4. Activate the environment. If conda
created the environment correctly, you should be able to activate it using conda activate path/to/environment
.
Short version:
conda activate ./env
Long version:
conda activate /Users/daniel/pytorch-test/env
Note: It's important to activate your environment every time you'd like to work on projects that use the software you install into that environment. For example, you might have one environment for every different project you work on. And all of the different tools for that specific project are stored in its specific environment.
If activating your environment went correctly, your terminal window prompt should look something like:
(/Users/daniel/pytorch-test/env) daniel@Daniels-MBP pytorch-test %
5. Now we've got a Conda environment setup, it's time to install the software we need.
Let's start by installing PyTorch 1.12.0+ for Mac from the PyTorch install page.
Note: As of June 30 2022, accelerated PyTorch for Mac (PyTorch using the Apple Silicon GPU) is still in beta, so expect some rough edges.
pip3 install torch torchvision torchaudio
If it worked, you should see a bunch of stuff being downloaded and installed for you.
7. Install common data science packages.
If you'd like to work on other various data science and machine learning projects, you're likely going to need Jupyter Notebooks, pandas for data manipulation, NumPy for numeric computing, matplotlib for plotting and Scikit-Learn for traditional machine learning algorithms and processing functions.
To install those in the current environment run:
conda install jupyter pandas numpy matplotlib scikit-learn tqdm
8. Test it out. To see if everything worked, try starting a Jupyter Notebook and importing the installed packages.
# Start a Jupyter notebook
jupyter notebook
Once the notebook is started, in the first cell:
import torch
import numpy as np
import pandas as pd
import sklearn
import matplotlib.pyplot as plt
print(f"PyTorch version: {torch.__version__}")
# Check PyTorch has access to MPS (Metal Performance Shader, Apple's GPU architecture)
print(f"Is MPS (Metal Performance Shader) built? {torch.backends.mps.is_built()}")
print(f"Is MPS available? {torch.backends.mps.is_available()}")
# Set the device
device = "mps" if torch.backends.mps.is_available() else "cpu"
print(f"Using device: {device}")
If it all worked, you should see something like:
PyTorch version: 1.12.0
Is MPS (Metal Performance Shader) built? True
Is MPS available? True
Using device: mps
Note: See more on running MPS as a backend in the PyTorch documentation.
9. To run data/models on an Apple Silicon GPU, use the PyTorch device name "mps"
with .to("mps")
. MPS stands for Metal Performance Shaders, Metal is Apple's GPU framework.
import torch
# Set the device
device = "mps" if torch.backends.mps.is_available() else "cpu"
# Create data and send it to the device
x = torch.rand(size=(3, 4)).to(device)
x
Finally, you should get something like this:
tensor([[2.6020e-01, 9.6467e-01, 7.5282e-01, 1.8063e-01],
[7.0760e-02, 9.8610e-01, 6.5195e-01, 7.5700e-01],
[3.4065e-01, 1.8971e-01, 6.0876e-01, 9.3907e-01]], device='mps:0')
Congratulations! Your Apple Silicon device is now running PyTorch and a handful of other helpful data science and machine learning libraries.
To see if it really worked, try running the 01_cifar10_tinyvgg.ipynb
notebook on GitHub end-to-end on your local machine and see how it goes.
